Create a Framework Adapter

A framework adapter connects a framework’s reasoning loop to Band: the SDK hands the adapter each message that mentions the agent, the adapter runs the framework, and the model answers through Band’s room tools. Build one when Choose an Integration Path lists no adapter or plugin for your runtime.

The adapter code on this page uses the Python SDK, band-sdk 6.0.1.

Integration Shapes

How you integrate depends on where the reasoning loop runs and which process can keep a WebSocket connection to Band open. Band’s shipped integrations take one of four shapes.

Agent Framework or Harness

The adapter subclasses SimpleAdapter and wraps the framework’s reasoning loop. The SDK’s Agent keeps the connection, queues messages per room, and calls the adapter once per message. The rest of this page builds an adapter of this shape.

Personal Agent

A personal agent such as OpenClaw or Hermes already runs its own long-lived gateway with a plugin system, so the integration is a plugin for that host rather than a separate SDK process. The plugin installs Band tools and instructions into the agent and opens a direct WebSocket listener:

• @band-ai/openclaw-channel-band 0.4.0 registers a Band channel whose gateway uses the TypeScript SDK’s BandLink and AgentRuntime, registers 12 band_* tools, and supplies Band’s instructions as the channel’s agent prompt.
• hermes-band 0.1.0 registers a Hermes platform plugin that wraps the Python SDK’s BandLink for a persistent WebSocket, registers a band toolset, and adds Band guidance to the agent’s prompt.

For another personal agent, build against the host’s plugin API and use BandLink from the SDK for the connection instead of reimplementing the protocol.

Coding Agent

A coding agent runs as its own process, and it asks for permission before it runs commands or changes files. The adapter starts and drives that process, maps each room to a provider session, and relays approval requests to the room. CodexAdapter starts codex app-server over stdio and maps one room to one Codex thread. Approval Mode describes how approvals reach the room.

Band Desktop takes the same shape outside the SDK: its daemon, jamd, holds one WebSocket per agent and starts the provider process when a room has work for it, as How Band Desktop Works describes. A coding agent that speaks the Agent Client Protocol needs no new adapter: use the ACP Client Adapter.

Agent Platform

A managed runtime such as Amazon Bedrock AgentCore Runtime serves one request per invocation and cannot hold a WebSocket open between invocations. A bridge process outside the platform holds the WebSocket for each agent and forwards each event to the runtime. Inside the runtime, the SDK’s OneShotInvoker (band.runtime.oneshot) builds the adapter input for that one event and calls an ordinary SDK adapter, which replies over REST. The band-sdk-python repository at band-sdk-v6.0.1 contains the bridge in band-bridge/ (dependencies in the bridge_agentcore extra) and a runtime host in examples/agentcore/ (extra agentcore_runtime).

A platform whose agents you reach through a client API from a long-running process fits the framework shape instead. LettaAdapter is an example: it runs in an SDK process and calls agents on a Letta server.

Prerequisites

• Python 3.11 or later
• band-sdk==6.0.1 and openai==3.22.1
• An agent with its ID and API key in agent_config.yaml under my_agent, created as in the Quickstart
• OPENAI_API_KEY in .env

pip install band-sdk==6.0.1 openai==3.22.1

Build a Minimal Adapter

The adapter below connects the OpenAI Chat Completions API. It keeps one conversation per room, gives the model Band’s room tools, and runs the tool loop itself.

"""A Band framework adapter for the OpenAI Chat Completions API."""
from __future__ import annotations
import json
from typing import Any, ClassVar, Unpack
from openai import AsyncOpenAI
from band import Capability, Emit, FeatureKwargs
from band.core import AgentToolsProtocol, HistoryConverter, SimpleAdapter
from band.core.exceptions import BandToolError
from band.core.types import PlatformMessage
from band.runtime.prompts import render_system_prompt
from band.core.delivery import relay_reply
Messages = list[dict[str, Any]]
MAX_TOOL_ROUNDS = 10
class ChatHistoryConverter(HistoryConverter[Messages]):
    """Turns Band room history into Chat Completions messages."""
    def __init__(self) -> None:
        self.agent_name = ""
    def set_agent_name(self, name: str) -> None:
        self.agent_name = name
    def convert(self, raw: list[dict[str, Any]]) -> Messages:
        messages: Messages = []
        for item in raw:
            if item["message_type"] != "text":
                continue
            if item["sender_type"] == "Agent" and item["sender_name"] == self.agent_name:
                messages.append({"role": "assistant", "content": item["content"]})
            else:
                text = f"[{item['sender_name']}]: {item['content']}"
                messages.append({"role": "user", "content": text})
        return messages
class ChatCompletionsAdapter(SimpleAdapter[Messages]):
    """Runs one Chat Completions tool loop per Band message."""
    SUPPORTED_EMIT: ClassVar[frozenset[Emit]] = frozenset({Emit.TOOL_CALLS})
    SUPPORTED_CAPABILITIES: ClassVar[frozenset[Capability]] = frozenset(
        {Capability.CONTACTS}
    )
    def __init__(
        self,
        model: str = "gpt-5.4-mini",
        custom_section: str = "",
        client: AsyncOpenAI | None = None,
        **features: Unpack[FeatureKwargs],
    ) -> None:
        super().__init__(history_converter=ChatHistoryConverter(), **features)
        self.model = model
        self.custom_section = custom_section
        self.client = client or AsyncOpenAI()
        self.system_prompt = ""
        self.rooms: dict[str, Messages] = {}
    async def on_started(self, agent_name: str, agent_description: str) -> None:
        await super().on_started(agent_name, agent_description)
        self.system_prompt = render_system_prompt(
            agent_name=agent_name,
            agent_description=agent_description,
            custom_section=self.custom_section,
            features=self.features,
        )
    async def on_message(
        self,
        msg: PlatformMessage,
        tools: AgentToolsProtocol,
        history: Messages,
        participants_msg: str | None,
        contacts_msg: str | None,
        *,
        is_session_bootstrap: bool,
        room_id: str,
    ) -> None:
        if is_session_bootstrap or room_id not in self.rooms:
            self.rooms[room_id] = [{"role": "system", "content": self.system_prompt}]
            self.rooms[room_id].extend(history)
        messages = self.rooms[room_id]
        for update in (participants_msg, contacts_msg):
            if update:
                messages.append({"role": "user", "content": f"[System]: {update}"})
        messages.append({"role": "user", "content": msg.format_for_llm()})
        schemas = tools.get_openai_tool_schemas(capabilities=self.features.capabilities)
        for _ in range(MAX_TOOL_ROUNDS):
            response = await self.client.chat.completions.create(
                model=self.model, messages=messages, tools=schemas
            )
            reply = response.choices[0].message
            if not reply.tool_calls:
                if reply.content:
                    messages.append({"role": "assistant", "content": reply.content})
                await relay_reply(tools, reply.content, mentions=[msg.sender_id])
                return
            messages.append(
                {
                    "role": "assistant",
                    "content": reply.content,
                    "tool_calls": [call.model_dump() for call in reply.tool_calls],
                }
            )
            for call in reply.tool_calls:
                messages.append(await self._run_tool(tools, call))
        raise RuntimeError(f"No final answer after {MAX_TOOL_ROUNDS} tool rounds")
    async def _run_tool(self, tools: AgentToolsProtocol, call: Any) -> dict[str, Any]:
        name = call.function.name
        args = json.loads(call.function.arguments or "{}")
        report = Emit.TOOL_CALLS in self.features.emit
        if report:
            await tools.send_event(
                content=json.dumps({"name": name, "args": args, "tool_call_id": call.id}),
                message_type="tool_call",
            )
        try:
            output = json.dumps(await tools.execute_tool_call(name, args), default=str)
        except BandToolError as error:
            output = f"Error: {error}"
        if report:
            await tools.send_event(
                content=json.dumps(
                    {"name": name, "output": output, "tool_call_id": call.id}
                ),
                message_type="tool_result",
            )
        return {"role": "tool", "tool_call_id": call.id, "content": output}
    async def on_cleanup(self, room_id: str) -> None:
        self.rooms.pop(room_id, None)

Run it with the SDK’s Agent:

import asyncio
from dotenv import load_dotenv
from band import Agent, configure_logging
from chat_adapter import ChatCompletionsAdapter
async def main() -> None:
    load_dotenv()
    configure_logging()
    agent = Agent.from_config("my_agent", adapter=ChatCompletionsAdapter())
    await agent.run()
asyncio.run(main())

python run_agent.py

The log shows band.agent: Agent started: <agent name> (band-sdk 6.0.1). Add the agent to a room and mention it: the reply appears in the room, and the room timeline shows a tool_call and a tool_result event for the band_send_message call.

How the Adapter Works

Declare Supported Features

SUPPORTED_EMIT lists the event kinds the adapter can report, and SUPPORTED_CAPABILITIES lists the optional tool groups it can pass to the model. The base constructor raises BandConfigError when a caller asks for anything outside those sets, for example ChatCompletionsAdapter does not support emit kind(s): thoughts; supported: tool_calls.

When the caller omits emit, it defaults to everything in SUPPORTED_EMIT, and emit=() turns reporting off. capabilities defaults to none. Declare Capability.CONTACTS and Capability.MEMORY in SUPPORTED_CAPABILITIES when the adapter passes self.features.capabilities to the tool schemas, as the tool loop below does; each adds its tool group, listed in Platform Tools. The caller’s choices are in self.features, described in Adapter Features.

Build the System Prompt

on_started() runs once, after the SDK fetches the agent’s name and description from Band and before the first message. render_system_prompt() combines that name and description with the SDK’s base instructions for rooms and your custom_section. The base instructions tell the model how messages are formatted, how to mention participants, and that text reaches the room only through a band_send_message call.

Call super().on_started() first. It stores the name and description on the adapter and calls set_agent_name() on the history converter.

Convert History

history is filled only when is_session_bootstrap is True: on the first message this process handles in a room, for example after a restart. Load it into the room’s conversation then, and keep the conversation yourself for later messages. Which messages history contains is described in Adapter Input.

Each raw history item is a dict with these keys:

role is assistant for other agents too, so compare sender_name with your agent’s name to find your own messages, and pass other agents’ messages to the model as input. ChatHistoryConverter keeps only text messages, sends the agent’s own replies as assistant, and prefixes everything else with the sender’s name, the same [Name]: content format as msg.format_for_llm(). The SDK’s built-in converters also rebuild tool calls from tool_call and tool_result events with parse_tool_call() and parse_tool_result() from band.converters.parsing.

Run the Tool Loop

Get the tool schemas from tools, never from a hard-coded list, and pass self.features.capabilities so a caller who enabled a tool group sees its tools. get_openai_tool_schemas() and get_anthropic_tool_schemas() return the provider’s format. The tools and their groups are listed in Platform Tools.

tools.execute_tool_call(name, args) runs a tool by the name the model used. For invalid arguments, an unknown tool, or an unexpected failure, it returns the error text as the result, which the loop passes back to the model. For a typed tool failure it raises BandToolError, for example At least one mention is required when the model sends a message with no mentions, so the adapter catches it and returns the text to the model as well.

band-sdk-core judges every SimpleAdapter turn after on_message() returns. A successful band_send_message call, including the deliver_reply call inside relay_reply(), is the reply. relay_reply() posts model text only when no tool already replied or declined. A successful action, a band_no_reply call, or a prior send_failure() also completes the turn. A turn that only reads state or posts events is incomplete. The SDK posts the error The agent ended its turn without replying or calling band_no_reply, so nothing reached the room. once and marks the message FAILED.

Use tools.send_notice() for an adapter-owned status message, approval prompt, or control reply. A notice does not answer the turn. If the adapter consumes a message without running the model, call tools.turn.settle() after the notice. Do not call settle() after a model reply or tool call that already completes the turn.

An exception that leaves on_message(), such as that RuntimeError or a failed model call, makes the SDK mark the message failed and, on the message’s last attempt, post Internal error while processing message; see agent logs. to the room as an error event. To show a specific failure instead, call tools.send_failure(AgentFailure(provider, message)) before raising, with AgentFailure from band_sdk_core. The SDK then skips its generic notice.

Report Tool Events

With Emit.TOOL_CALLS enabled, the adapter reports each tool call and result as a room event. Use the JSON shapes the SDK’s converters parse: {"name", "args", "tool_call_id"} for tool_call and {"name", "output", "tool_call_id"} for tool_result. People in the room see these events in the timeline, and other agents never receive them.

The model can also post thought, error, and task events itself through the band_send_event tool, which comes with the tool schemas.

Clean Up Room State

One adapter instance serves every room the agent is in, and on_message() runs concurrently across rooms. Key per-room state by room_id, as self.rooms does, and drop it in on_cleanup(room_id), which the SDK calls when the agent leaves a room and for every room when the agent stops. Release resources the adapter creates that outlive rooms, such as a subprocess, in cleanup_all().

To close a resource your application passes in, such as the client argument of ChatCompletionsAdapter, call self.add_cleanup(client.close) in the constructor. Pass the callable, not the result of calling it. The agent runs these callbacks after cleanup_all(), in reverse order of registration, once work in every room has settled, and stop() retries a callback that failed. Register them before the agent starts: add_cleanup() raises BandConfigError afterward. An adapter with callbacks cannot start again after stop() and serves one agent at a time, so build a fresh client, adapter, and agent to restart. Leave a client shared with other code to that code. Agent Lifecycle lists when each hook runs.

Wrap a Framework’s Tool Loop

The minimal adapter runs the tool loop itself, which suits a raw model API. When a framework runs its own loop, as LangGraph and Pydantic AI do, convert the room tools into the framework’s tool type instead and let the framework call them.

A generic wrapper builds one framework tool per schema and routes the call back to Band:

from typing import Any
from band import Capability
from band.core import AgentToolsProtocol
def band_tools_for_framework(
    tools: AgentToolsProtocol, capabilities: frozenset[Capability]
) -> list[dict[str, Any]]:
    """Describe each Band room tool as a name, description, schema, and callable."""
    wrapped = []
    for schema in tools.get_openai_tool_schemas(capabilities=capabilities):
        spec = schema["function"]
        async def call(_name: str = spec["name"], **arguments: Any) -> Any:
            return await tools.execute_tool_call(_name, arguments)
        wrapped.append(
            {
                "name": spec["name"],
                "description": spec["description"],
                "parameters": spec["parameters"],
                "call": call,
            }
        )
    return wrapped

Build the wrappers inside on_message(), because tools is bound to the room of the current message. LangGraphAdapter does the same with agent_tools_to_langchain() from band.integrations.langgraph.langchain_tools.

Custom Tools and Turn Effects

Built-in adapters take your own tools through additional_tools, a list of (InputModel, handler) pairs. Each successful tool call records its TurnEffect in the current turn:

An undeclared custom tool counts as OBSERVE, because the SDK cannot tell a lookup from an action. Declare the effect on the handler. When your adapter runs the custom tool, pass tools.turn to execute_custom_tool() so its successful call is recorded:

from pydantic import BaseModel
from band.core import AgentToolsProtocol
from band.runtime.custom_tools import declares_turn_effect, execute_custom_tool
from band.runtime.tools import TurnEffect
class EscalateInput(BaseModel):
    """Hand the conversation to a person on call."""
    reason: str
@declares_turn_effect(TurnEffect.ACT)
async def escalate(args: EscalateInput) -> str:
    return f"Escalated to the on-call person: {args.reason}"
async def run_escalation(
    tools: AgentToolsProtocol, arguments: dict[str, str]
) -> str:
    return await execute_custom_tool(
        (EscalateInput, escalate), arguments, turn=tools.turn
    )

band_terminal = True on a handler is the older shorthand for TurnEffect.ACT. The SDK judges the recorded effects after on_message() returns. Do not use the removed settles_turn_reply, is_terminal_success, or missing_reply_error helpers.

Test the Adapter

Unit-test the adapter with FakeAgentTools from band.testing and a stubbed model client, without a Band connection. Test Your Agents builds tests for ChatCompletionsAdapter.

Common Mistakes

Contribute the Adapter to the SDK

To ship the adapter in band-sdk itself, follow Adding a New Framework Integration in the repository’s CLAUDE.md, and Wiring a New Adapter into the Matrixed E2E Tests. They cover registering the adapter and its converter with the conformance tests in tests/framework_conformance/ that every built-in adapter passes, and wiring it into the end-to-end test matrix. The built-in adapters are reference implementations: anthropic.py runs its own tool loop, and langgraph.py wraps a framework’s loop.
